Silicone Underwear Dispenser

Your Professional Silicone Underwear Dispenser Manufacturers

Dongguan Cretech Intelligent Machinery Co.,Ltd is a non-standard automation equipment customization manufacturer that integrates research and development, design, production, sales, and service. We constantly focus on technological development and combine advanced technological achievements from both domestic and international sources to provide customers with high-quality products that offer excellent value for money. We adhere to the principles of prioritizing technology, providing superior service, and conducting business with integrity. We seek extensive cooperation with both new and existing customers. Feel free to contact us for inquiries or visit us for guidance!

Why Choose Us

Product Categories
Underwear gluing machine, textile equipment gluing machine, hot melt adhesive dispensing machine, T8 automatic assembly line equipment, automatic panel light assembly line equipment, automatic dispensing machine, automatic soldering machine equipment, automatic screw locking machine, robotic arm, and other intelligent devices.

Production Market
China, Russia, Sri Lanka, Bangladesh, India, Vietnam, Turkey, the United States, etc. have cooperated with many large international underwear factories, with an annual turnover exceeding 30 million.

Product Application
Our products are widely used in industries such as textiles, clothing, leather, lighting, electronic components, electronic devices, and industrial control.

Our Service
Provide comprehensive pre-sales, in sales, and after-sales services, including technical support, Track usage and give positive feedback. Quick response within 24 hours.

Features of Silicone Underwear Dispenser

1. Desktop-type can be placed on the production line.

2. High-rigidity aluminum alloy multi-axis design ensures reliability and accuracy.

3. Glue automatic feeding, glue thickness, glue speed, dispensing time, stop time can be set parameters, the glue stability is high.

4. Flexibility: Standard universal fixtures are suitable for a wide range of production requirements.

5. More user-friendly touch screen or teaching pendant operation, easy to operate. External technical parameters and manual test functions can be directly adjusted by the technician.

6. It has a variety of functions, such as drawing points, lines, polygons, arcs, circles, irregular curves, continuous tween and three-axis movement.

7. The dispensing machine can work without a teach pendant connection.

8. Various types of distribution valves are available, such as screw distribution valves, metering valves, and injection valves to meet different production requirements.

Working Principle

1. Put the glue inside the syringe, cover it with the lid, and install it on the fixture.
2. Adjust the controller according to demanded glue amount in the unit product, and save the data when setting is finished.
3. Make trial production to check if everything goes well.

Application of Silicone Underwear Dispenser

Seamless underwear

Increased elasticity and anti-slip features to ensure comfortable wearing.

One-piece bra

Improves tension and breathability to prevent allergies.

Underwear

Anti-slip coating, especially suitable for sports underwear.

Socks

The silicone coating on the soles of the feet can effectively prevent slipping and increase safety.

Cuff and navel protector

Silicone coating for enhanced comfort and anti-slip properties.

Cups and panels

Give the product greater functionality and decoration.

Specification of Silicone Underwear Dispenser

Silicone Dispensing Machine CZ-NY302
Work Stroke (XYZ)	920mm720mm40mm	Style	Silicone (straight line, curved line, adhesive scraper)
Max Speed	500mm/S (XY)400mm/S (Z)	Operating Power	AC220V 50~60HZ 1.5KW
Repeat Precision	士0.05mm	Device Weight	1760kg
Dispensing Precision	土0.01	Device Size	2090mm1390mm1600mm
Driving Mode	Lead Screw + Servo	Dispensing Bucket	AB double buckets (Mix two buckets of glue in a 1:1 ratio.)
Motor System	Gemicon Closed-loop Motor	Working System	CRETECH Industrial Control Schematic System
Glue Supply System	CRETECH Double Pressure Buckets System	Fuselage Mechanism	Welded frame, steel bucket, plastic
Dispensing Way	Gear pump for dispensing glue	Fuselage Mechanism	Welded frame, steel bucket, plastic
Double Dispensing Valves	It can achieve three effects: silicone round strip, silicone flat strip, and silicone scraper. The valve can rotate freely, so it can achieve various graphic effects.

Customization

Customized logo	Min. order: 1 pieces
Customized packaging	Min. order: 1 pieces
Customize workplatform size	Min. order: 1 pieces
Graphic customization	Min. order: 1 pieces

Packaging & Shipping

FAQ

Q: How can i get the price?

A: We usually quote within 24 hours after we get your inquiry(Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.

Q: Where is your company address?

A: Our company is located at Building 1, No. 3 Sunshine Road, Caibai, Daojiao Town, Dongguan City, Guangdong Province, China. We welcome customers to visit our company!

Q: May I visit your company?

A: Of course you can! We warmly welcome customers to come to our company to learn about our equipment.

Q: Can I buy samples placing orders?

A: Yes.Please feel free to contact us.

Q: What is your lead time?

A: It depends on the order quantity and the season you place the order. Usually we can ship within 7-15 days for small quantity,and about 30 days for large quantity.

Q: What is your payment term?

A: T/T,Western Union,Alipay,MoneyGram,and Paypal.This is negotiable.

Q: What is the shipping method?

A: It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).Please confirm with us before placing orders.

Q: How can I know the product is suitable for me?

A: Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.

We're well-known as one of the leading silicone underwear dispenser manufacturers and suppliers in China. Please rest assured to wholesale customized silicone underwear dispenser made in China here from our factory. Contact us for more details.
